A proposal for standardized data models and exchange information protocols applicable in centralized metering systems
Article Sidebar
Submitted:
Nov 30, 2015
Published:
May 10, 2017
Citations
Downloads
Download data is not yet available.
The total or partial reproduction of the contents of the journal for educational, research, or academic purposes is authorized as long as the source is cited. For reproduction for other purposes, express authorization from the Sello Editorial Universidad de Medellín is required.
Main Article Content
Abstract
The non-technical energy losses reduction strategies have stimulated the development of centralized metering systems (cms) in Latin America. Furthermore to include ami systems basic functions, the cms embed the measurement of multiple users in a cabinet. To avoid the utility customers getting access to the energy meter, each cabinet is mounted on top of an electrical pole. Currently, the major commercially available cms equipment is setting up with several technologies, which involves owner interfaces and data models. This issue generates an interoperability problem since international standards are based on measurement architectures for the use of individual meters. This paper proposes a set of both information exchange protocols and standardized data models that could be implemented in cms equipments.
How to Cite
Rodríguez Cardona, C. F., Calvache Vallejo, B. A., & Caicedo Bravo, E. F. (2017). A proposal for standardized data models and exchange information protocols applicable in centralized metering systems. Revista Ingenierías Universidad De Medellín, 16(30), 149–167. https://doi.org/10.22395/rium.v16n30a8
Article Details
References
